Xingang Melamine Chipboard
Glue：XINGANG BIOMIMETIC GLUE(HENF GRADE)
Size：1220 x2440/2800x9-25mm/as requested
Density：500-700 kg/m3
Surface Design：Melamine paper,PET Nature Veneers or as requested
Send Inquiry
Product Details ofXingang Melamine Chipboard
| Test result | ||||||
| NO. | Testing item | Unit | Standard | Testing result | Conclusion | |
| 1 | Static Bending Strength | Mpa | ≥11.0 | 15.1 | Pass | |
| 2 | Elastic Modulus | Mpa | ≥1600 | 3290 | Pass | |
| 3 | Internal Bonding Strength | Mpa | ≥0.35 | 0.47 | Pass | |
| 4 | Surface Bonding Strength | Mpa | ≥0.60 | 1.75 | Pass | |
| 5 | 2 Hours Thickness Swelling Rate | % | ≤8.0 | 0.3 | Pass | |
| 6 | Moisture Content | % | 3.0 ~ 13.0 | 5.9 | Pass | |
| 7 | Density | g/cm3 | 0.60 ~ 0.90 | 0.69 | Pass | |
| 8 | Screw Holding Capability | Surface | N | ≥900 | 1250 | Pass |
| Edge | ≥600 | 930 | Pass | |||
| 9 | Surface resistance to hot and cold | - | No cracks, bubbling, discoloration, wrinkles, etc. | No cracks, no bubbling, no discoloration, no wrinkles | Pass | |
| 10 | Surface Scratch Resistance | - | ≥1.5N | 1.5N No more than 90% of continuous scratches on the surface | Pass | |
| 11 | Surface Wearable | Wear values | mg/100r | ≤80 | 35 | Pass |
| Surface condition | - | After grinding for 100 revolutions, more than 50% of the pattern should be retained. | 75% of the pattern is retained after 100 revolutions of grinding | Pass | ||
| 12 | Surface dry heat resistance | - | Reach level 4 or above | level 4 | Pass | |
| 13 | Surface Contamination Corrosion Resistance | - | Reach level 5 or above | level 5 | Pass | |
| 14 | Surface Cracking Resistance | - | Reach level 4 or above | level 5 | Pass | |
| 15 | Surface Water Vapor Resistance | - | Reach level 4 or above | level 4 | Pass | |
| 16 | Colour Fastness | Level | Blue wool cloth level 6, | Greater than 4 levels of grayscale card | Pass | |
| Reach grayscale card level 4 | ||||||
| Null | ||||||
| Notes | ---- | |||||
Originating from biomimetics, deriving inspiration from nature!
Xingang Biomimetic Adhesive-0 formaldehyde,0 benzenen,and 0 Harmful Substance.has been successfully applied on a large scale in Xingang BiomimeticF-LSB,Xingang Biomimetic Super Strong Particle Board, Xingang Biomi-metic Plywood, Xingang Biomimetic MDF. The Xingang boards meet thenational standards in the physical & chemical properties ,and environ-mentally-friendly.
6 MAJOR FEATURES
- Biomimetic Technology
- Flexible Surface Technology,Addressing Embossing Problems
- High Bonding Strength, No Cracking or Layering
- Save Tools, not Easy to Break Edges
- The Entire Process is Non-Toxic, Pollution-Free Environmentally Friendly
- Healthy and Environmentally Friendly, with no Occupational Hazards, Requiring noSpecial Protective Measures
RAW MATERIALADVANTAGES IMPORTED PINE WOOD
Healthy Eco-friendly / Quality / Material
01
Pleasant Pine Aroma
Large-diameter pine imported from New Zealand features a coarse and uniform structure.After peeling and water washing processing, the board is pure and free ofimpurities, emitting the natural fragrance of pine wood.
02
Sturdy and Durable
New Zealand radiata pine has low oil content, low shrinkage rate,stable material properties, is resistant to cracking and deformation, has a long service life, low hardness, and is easy to process.
03
Good Processability
New Zealand radiata pine has strong plasticity, good stability,and flexible wood texture. The processed finished boards have uniform density, less impurities, high low-density strength, aresturdy and durable, and are easy to process without wearing down tools.
EOUIPMENT ADVANTAGES INDUSTRY 4.0 INTELLIGENT MANUFACTURING
The Xingang Super Strong Particle Board Project has introduced the first production line of Dieffenbach in Shandong Province,using Grubbas Super Particle Planer, ltalian Par Super Particle Screen and Air Flow Selection Machine,Dieffenbach Online Gluing and Mixing System, Dieffenbach Surface Air Flow Paving Machine,and Dieffenbach Continuous Press System, all of which are in line with international standards and leading the industry's development.
Annual production of 300,000m³ particleboard
Dieffenbach continuous press system
Annual production of 200,000m3 fiberboard
Yalian Ultra High speed Continuous Flat Pressing
Adopting high-performance integrated joints,the CRA series can increase the tempo by 25%,and the productivity can reach a new peak;the vibration suppression algorithm is upgraded to achieve a good anti-shaking effect;the full-parameter DH compensation algorithm and TrueMotion algorithm are supported,and the absolute positioning accuracy is 0.2 ~ 0.4 mm under the change of attitude movement,and the curved motion is precise and stable.
CORE ADVANTAGES
01.
Xingang Biomimetic Adhesive Developed by Academician Li Jian's team
0 Formaldehyde
0 Benzene
0 Harmful Substance
02.
China's First Near-Zero odor Health Product certification
Effectively solved the problem of furniture environmental pollution,and realized the effective control of the main health risk factors.
03.
24h+NationalEnvironmental Standards for Pregnant and lnfant Level
Rely on excellent quality and environmental performance,formaldehyde release ≤0.020mg/m3, environmental requirements than ENF level new national standard 20%.
04.
Antibacterial and Antiviral Efficacy
Primary Antibacterial Effect:lt has an antibacterial rate of up to 99.99% against Escherichia coli, Staphylococcus aureus, Klebsiella pneumoniae, and Pseudomonas aeruginosa, achieving a first-class strong antibacterial effect.
Door-Wall-cabinet Integration
In order to meet the needs of users, four supporting customized systems have integrated by Xingang Group: the interior door system (including molding, frame boards, and door leaves), the wall panel system(including wooden decorative boards,wall panels,convex corner arcs, and concave corner arcs),the cabinet door system, and the door type system.These systems effectively address the technological challenges faced by panel furniture factories and contribute to creating one-stop, high-quality customized homes.
Functional Areas
Defined According to User's Floor Plan (Entrance Space, Living & Dining Room, Master Bedroom,Secondary Bedroom,Multi-functional Room, Kitchen, Wardrobe Room, Balcony)
Functional Cabinets (Movable Furniture)
Entryway Cabinet, TV Cabinet, Sideboard, Wardrobe,Tatami Mat Platform, Kitchen Cabinet, Closet Cabinet,Balcony Cabinet, Bookcase, Wine Cabinet,etc.
